Stanchion & End Fittings

Forward Handrail Stanchion - 6080

316 S.S. Forward Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/2"

Fastener - #10 (2)


Material: 316 Stainless Steel
Dimensions: H: 1-1/2"

Forward Handrail Stanchion - 6180

316 S.S. Forward Handrail Stanchion

Tube O.D. - 1"

Height - 1-3/4"

Fastener - #10 (2)


Material: 316 Stainless Steel
Dimensions: H: 1-3/4"

Center Handrail Stanchion - 6079

316 S.S. Center Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/2"

Fastener - #10 (2)


Material: 316 Stainless Steel
Dimensions: H: 1-1/2"

Center Handrail Stanchion - 6179

316 S.S. Center Handrail Stanchion

Tube O.D. - 1"

Height - 1-3/4"

Fastener - #10 (2)


Material: 316 Stainless Steel
Dimensions: H: 1-3/4"

Center Handrail Stanchion - 6215

316 S.S. Center Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/2" (Left)

Fastener - #10 (2)

With 1/4-28 Set Screws, P/N 6249 for fastening stanchion to deck


Material: 316 Stainless Steel
Dimensions: H: 1-1/2" (Left)

Center Handrail Stanchion - 6216

316 S.S. Center Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/2" (right)

Fastener - #10 (2)

With 1/4-28 Set Screw, P/N 6249 for fastening stanchion to deck


Material: 316 Stainless Steel
Dimensions: H: 1-1/2" (Right)

Center handrail Stanchion - 6091

316 S.S. Center Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/2"

Fastener - With 1/4-28

Set Screw Weight - 5.0 oz.


Material: 316 Stainless Steel


Handrail Stanchion - S-1489

CP/Zamac Center Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/2"

Fastener - #10(2)

For Fresh Water Installation only


Material: C.P. Zamac
Dimensions: H: 1-1/2"

Aft Handrail Stanchion - 6081

316 S.S. Aft Handrail Stanchion

Tube I.D. - 7/8"

Height - 1-1/2"

Fastener - #10 (2)


Material: 316 Stainless Steel
Dimensions: H: 1-1/2"

Aft Handrail Stanchion - 6181

316 S.S. Aft Handrail Stanchion

Tube O.D. - 1"

Height - 1-3/4"

Fastener - #10 (2)


Material: 316 Stainless Steel
Dimensions: H: 1-3/4"

Aft Handrail Stanchion - 6225

316 S.S. Aft Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/3" (left)

Fastener - #10 (2)

With 1/4-28 Set Screw, P/N 6249


Material: 316 Stainless Steel
Dimensions: H: 1-1/2" (Left)

Aft Handrail Stanchion - 6226

316 S.S. Aft Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/3" (Right)

Fastener - #10 (2)

With 1/4-28 Set Screw, P/N 6249


Material: 316 Stainless Steel
Dimensions: H: 1-1/2" (Left)

Handrail Stanchion - S-1488

CP/Zamac Aft Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/2"

Fastener - #10(2)

For Fresh Water Installation only


Material: C.P. Zamac
Dimensions: H: 1-1/2"

Handrail Stanchion - S-1487

CP/Zamac Aft Handrail Stanchion

Tube O.D. - 7/8"

Height - 1-1/2"

Fastener - #10(2)

For Fresh Water Installation only


Material: C.P. Zamac
Dimensions: H: 1-1/2"

Stanchion - 6279

316 S.S. 90° Stanchion

Tube O.D. - 7/8"

Height - 1-1/2"

Type -Center

Fastener - #10 (2)

Stanchion - 6280

316 S.S. 90° End Stanchion

Tube O.D. - 7/8"

Height - 1-1/2"

Fastener - #10(2)

End-Bottom Mounted 90° - 6090

316 S.S. End-Bottom Mounted 90°

Tube O.D. - 7/8"

Height - 1-1/2"

Base - 6-13/16" x 1-3/8"


Material: 316 Stainless Steel
Dimensions: H: 1-1/2"

End-Top Mounted - 6190

316 S.S. End-Bottom Mounted 90 degrees

Tube O.D. - 1"

Height - 1-1/2"

Base - 6-7/8" x 1-1/2"


Material: 316 Stainless Steel
Dimensions: H: 1-1/2"

Bottom Mount End - S-1494

CP/Zamac End-Bottom Mounted 90°

Tube O.D. - 7/8"

Height - 1-1/2"

Base - 6-13/16" x 1-3/8"

For Fresh Water Installation only

End-Top Mounted - 6130

316 S.S. End-Top Mounted 90°

Tube O.D. - 7/8"

Height - 1-1/2"

Base - 6-1/2" x 1-1/2"


Material: 316 Stainless Steel

Rail End - 6050

316 S.S. 16-1/2" Rail End (End-Out)

Tube O.D. - 7/8"

Wall Thickness - .049"

Fastener - #10


Material: 316 Stainless Steel


Rail End - 6048

316 S.S. 5-1/2 degree Rail End (End-out)

Wall Thickness: .049"

Tube O.D.: 7/8"

Fastener: #10


Material: 316 Stainless Steel


Rail End - 6049

316 S.S. 5-1/2 degree Rail End (End-Out)

Tube O.D. - 7/8"

Size - 1-3/16" x 5"

Fastener - #10(2)


Material: 316 Stainless Steel



Rail End - S-1495

CP/Zamac 5-1/2 degree Rail End (End-Out)

Tube O.D. - 7/8"

Size - 1-3/16" x 5"

Fastener - #10(2)

For Fresh Water Installation only


Material: C.P. Zamac


Blind Base - 6084

316 S.S. 7/8" - 5/1/2° Blind Base

Tube O.D. - 7/8"

Base - 3-3/8" x 1-1/2"

Fastener - 1/4"(2)

Blind Base - 6184

316 S.S. 5-1/2°Blind Base

Base - 3-9/16" x -1/2"

Tube O.D. - 1"

Fastener - 1/4" (2)

Rectangular Base - 11901

316 S.S. degree Rectangular Base

Tube O.D. - 1"

Base - 3-1/2" x 3"

Fastener - 1/4" (4)

With 1/4-2 8 set screws (P/N 6249)

Bullet End - 6229

316 S.S. Bulllet End

Tube O.D. - 7/8"

Length - 7/8"


Material: 316 Stainless Steel
Dimensions: L: 7/8"
